Brainchild PR10 User Manual

Page 115 of 479
Parameter
Notation
Parameter
Description
Range
Low*B
Range
High*B
Default
Value*C
Unit*E
OFST
Offset Value for P control
0
100.0
25.0
%
REFC
Reference Constant for Specific
Function
0
60
2
SHIF
PV1 Shift (offset) Value
-200.0°C
(-360.0°F)
200.0°C
(360.0°F)
0.0
PV1
PB1
Proportional Band 1 Value
0
500.0°C
(900.0°F)
10.0°C
(18.0°F)
PV
TI1
Integral Time 1 Value
0
1000
100
Sec
TD1
Derivative Time 1 Value
0
360.0
25.0
Sec
CPB
Cooling Proportional Band Value
1
255
100
% of
PB
DB
Heating-Cooling Dead Band
-36.0
36.0
0
% of
PB
SP2
Set point 2
*B2
*B2
37.8°C
(100.0°F
PV
PB2
Proportional Band 2 Value
0
500.0°C
(900.0°F)
10.0°C
(18.0°F
PV
TI2
Integral Time 2 Value
0
1000
100
Sec
TD2
Derivative Time 2 Value
0
360.0
25.0
Sec
O1HY
Output1 ON-OFF Control Hysteresis
0.1
55.6°C
(100.0°F
0.1
PV
A1HY
Hysteresis Control of Alarm1
0.1
10.0°C
(18.0°F)
0.1
*E1
A2HY
Hysteresis Control of Alarm2
0.1
10.0°C
(18.0°F)
0.1
*E2
PL1
Output 1 Power Limit
0
100
100
%
PL2
Output 2 Power Limit
0
100
100
%
FUNC
Function Complexity Level
0 *B3
1 *B3
1
COMM
Communication Interface Type
0 *B4
8 *B4
1
PROT
COMM Protocol Selection
0 *B5
0 *B5
0
ADDR
Address Assignment of Digital
COMM
1
255
BAUD
Baud Rate of Digital COMM
0 *B7
9 *B7
5
DATA
Data Bit count of
Digital COMM
0 *B8
1 *B8
1
PARI
Parity Bit of Digital COMM
0 *B9
2 *B9
0
STOP
Stop Bit Count of Digital COMM
0 *B10
1 *B9
0
AOFN
Analog Output Function
0 *B11
7 *B11
0
IN1
IN1 Sensor Type Selection
0 *B12
17 *B12
1 (0)
IN1U
IN1 Unit Selection
0 *B13
2 *B13
0 (1)
DP1
IN1 Decimal Point Selection
0 *B14
3 *B14
1
IN1L
IN1 Low Scale Value
-19999
45536
0
*E5
IN1H
IN1 High Scale Value
-19999
45536
1000
*E5
SP1L
SP1 Low Scale Value
-19999
45536
0.0°C
(32.0°F)
PV
