Brainchild PR10 User Manual

Page 25 of 479
Part no
Description
PM203
90-250VAC 47-63Hz portable power supply board with power switch for PR10 and
PR20
PM211
11-36VDC panel mount power supply board without power switch for PR10 and PR20
PM212
11-36VDC panel mount power supply board with power switch for PR10 and PR20
PM213
11-36VDC portable power supply board with power switch for PR10 and PR20
PM301
90-250VAC 47-63Hz panel mount power supply board without power Switch for PR30
PM302
90-250VAC 47-63Hz panel mount power supply board with power switch For PR30
PM303
90-250VAC 47-63Hz portable power supply board with power switch for PR30
PM311
11-36VDC panel mount power supply board without power switch for PR30
PM312
11-36VDC panel mount power supply board with power switch for PR30
PM313
11-36VDC portable power supply board with power switch for PR30
1-2 Accessories Ordering Code
Note:
❖ The rear slots of the recorder will accept certain Input or output cards only in any combination
based on selected model.
❖ The basic PC software is supplied free with the recorder. There is an additional charge for the
extensive Data Acquisition Software and communication ports of RS-232/422/485.
❖ The Ordering Code for various standard model Recorders with an AC supply and without any
additional options are as follows:
PR1003- 0A001000
PR2003- 0A001000
PR3006- 000A001000
1.9 Specifications
1.9.1 General Specifications
PR10
PR20
PR30
Number of Analog Input
3,6
3,6,12,18,24
6,12,18,24,30,36,42,48
Input Signals
Thermocouples: J, K, T, E, B, R, S, N, L, U, P, W5, W3, LR, A1, A2, A3, M
RTD: PT50, PT100, PT200, PT500,PT1000(α=0.00385), PT50,
PT100(α=0.00391), JPT50, JPT100, JPT200, JPT500, JPT1000(α=0.003916),
Cu10(α=0.00427),Cu50, Cu100(α=0.00426, 0.00428), Ni100, Ni200, Ni500,
Ni1000(α=0.00617), Current(mA),Voltage(Volts, mV)
Fastest Sampling rate
100msec/dot, Default setting : 1sec/dot
Calibration Correction
On-site Calibration possible or using Offset and Gain for correction
Power
90-250VAC, 47-63Hz, 52VA, 26W
maximum
11-36VDC, 26VA, 26W maximum
90-250VAC, 47-63Hz, 110VA, 62W
maximum,
11-36VDC, 62VA, 62W maximum (UL
Certification Not available)
Display Size
4.3”
5.6”
12.1”
Display Type
65K Colour, TFT Touch Screen
Display Resolution
480 x 272
640 x 480
1024 x 768
Backlight
LED
Display MTBF @25°C
30000 Hours
60000 Hours
CPU
ARM Cortex-A8, 1GHz
Internal Memory
256MB
External Storage
Max. Up to 32GB SD Card or USB Disk
