Brainchild PR10 User Manual

Page 404 of 479
Modbus Address
Notation
Register Name
Access
68
DI19
DI 19 process value
R
69
DI20
DI 20 process value
R
70
DI21
DI 21 process value
R
71
DI22
DI 22 process value
R
72
DI23
DI 23 process value
R
73
DI24
DI 24 process value
R
74
DO1
DO 1 process value
R
75
DO2
DO 2 process value
R
76
DO3
DO 3 process value
R
77
DO4
DO 4 process value
R
78
DO5
DO 5 process value
R
79
DO6
DO 6 process value
R
80
DO7
DO 7 process value
R
81
DO8
DO 8 process value
R
82
DO9
DO 9 process value
R
83
DO10
DO 10 process value
R
84
DO11
DO 11 process value
R
85
DO12
DO 12 process value
R
86
DO13
DO 13 process value
R
87
DO14
DO 14 process value
R
88
DO15
DO 15 process value
R
89
DO16
DO 16 process value
R
90
DO17
DO 17 process value
R
91
DO18
DO 18 process value
R
92
DO19
DO 19 process value
R
93
DO20
DO 20 process value
R
94
DO21
DO 21 process value
R
95
DO22
DO 22 process value
R
96
DO23
DO 23 process value
R
97
DO24
DO 24 process value
R
98
AO1
AO 1 process value
R
99
AO2
AO 2 process value
R
100
AO3
AO 3 process value
R
101
AO4
AO 4 process value
R
102
AO5
AO 5 process value
R
103
AO6
AO 6 process value
R
104
AO7
AO 7 process value
R
105
AO8
AO 8 process value
R
106
AO9
AO 9 process value
R
107
AO10
AO 10 process value
R
108
AO11
AO 11 process value
R
109
AO12
AO 12 process value
R
Note: If the register value is 65534, then there is a communication error.
8.1.1.2 AI / DI / DO / AO Channel Data (Float Type)
Modbus Address
Notation
Register Name
Access
1001
Reserve
Reserve
R
1003
AI1
AI 1 process value
R
1005
AI2
AI 2 process value
R
1007
AI3
AI 3 process value
R
1009
AI4
AI 4 process value
R
1011
AI5
AI 5 process value
R
1013
AI6
AI 6 process value
R
