Brainchild PR10 User Manual

Page 292 of 479
6.3.1 Panel Studio Software Installation
The panel studio Software will install the following components on the PC.
▪ Microsoft installer V3.1
▪ Microsoft.Net frame work V3.5 SP1
▪ Panel Studio Custom Screen Editing Software
▪ OPC server (Only Required for HMI)
▪ Demo projects (Only Required for HMI)
▪ Historical viewer
▪ HMI Remote viewer (Only Required for HMI)
6.3.1.1 System Requirements
Item
Minimum Requirements
System
IBM PC compatible computer with
Intel Pentium IV or above
Operating System
Windows XP or above
Memory
1 GB
Hard Disk
50 GB Free Space on the hard disk
Communication Ports
Ethernet Port
Others
USB Port
Licence
Optional USB Licence Key for
Symbol Factory
6.3.1.2 Software Installation
The Panel Studio software can be installed by following the below procedure.
1. Download the Panel Studio software form the manufacturer’s website.
2. Install latest dot Net software from Microsoft website
3. Install the software by double clicking the setupwizard.exe from Panel Studio folder.
