Brainchild PR10 User Manual

Page 406 of 479
Modbus Address
Notation
Register Name
Access
1127
DI15
DI 15 process value
R
1129
DI16
DI 16 process value
R
1131
DI17
DI 17 process value
R
1133
DI18
DI 18 process value
R
1135
DI19
DI 19 process value
R
1137
DI20
DI 20 process value
R
1139
DI21
DI 21 process value
R
1141
DI22
DI 22 process value
R
1143
DI23
DI 23 process value
R
1145
DI24
DI 24 process value
R
1147
DO1
DO 1 process value
R
1149
DO2
DO 2 process value
R
1151
DO3
DO 3 process value
R
1153
DO4
DO 4 process value
R
1155
DO5
DO 5 process value
R
1157
DO6
DO 6 process value
R
1159
DO7
DO 7 process value
R
1161
DO8
DO 8 process value
R
1163
DO9
DO 9 process value
R
1165
DO10
DO 10 process value
R
1167
DO11
DO 11 process value
R
1169
DO12
DO 12 process value
R
1171
DO13
DO 13 process value
R
1173
DO14
DO 14 process value
R
1175
DO15
DO 15 process value
R
1177
DO16
DO 16 process value
R
1179
DO17
DO 17 process value
R
1181
DO18
DO 18 process value
R
1183
DO19
DO 19 process value
R
1185
DO20
DO 20 process value
R
1187
DO21
DO 21 process value
R
1189
DO22
DO 22 process value
R
1191
DO23
DO 23 process value
R
1193
DO24
DO 24 process value
R
1195
AO1
AO 1 process value
R
1197
AO2
AO 2 process value
R
1199
AO3
AO 3 process value
R
1201
AO4
AO 4 process value
R
1203
AO5
AO 5 process value
R
1205
AO6
AO 6 process value
R
1207
AO7
AO 7 process value
R
1209
AO8
AO 8 process value
R
1211
AO9
AO 9 process value
R
1213
AO10
AO 10 process value
R
1215
AO11
AO 11 process value
R
1217
AO12
AO 12 process value
R
Note: If the register value is 3.0+E38, then there is a communication error.
8.1.1.3 Math Channel Data (Integer Type)
Modbus Address
Notation
Register Name
Access
201
Math1
Math 1 process value high word
R
202
Math1
Math 1 process value low word
R
203
Math2
Math 2 process value high word
R
