Page 152 of 479
5.2.5 Profile
This will allow the user to configure the ramp and soak profiles for PID process control card. The
recorder can be configured with maximum of 50 profiles with each 32 segments limited to 1000 segments in
total.
After entering the Configuration menu, select Profile then Press the “Enter” soft key to get into
Profile configuration menu. It displays the Profile Profile1 as the first Profile configuration page. Press
directional navigation keys at the bottom to select other profiles. Press directional keys
on the right hand side to select the configuration menu column. After completing
Configuration, press soft key, then press soft key to return to main display. All
configurations will be saved automatically.
