Page 168 of 479
5.5 Batch
This will allow the user to configure the batch configuration. This menu will be visible to the user
when batch is enable in instrument menu configuration. After entering the Configuration menu, select
“Batch” then Press the “Enter” key to get into Batch configuration menu. It displays the Display page
Page1 as the first display page configuration page. Press directional keys on the right
hand side to select the menu column. After completing Configuration, press soft key, then
press soft key to return to main display. All configurations will be saved automatically.
5.5.1 Name
Enables the User to define the name for Batch with a maximum of 18 characters.
Select “Name”, then Press “Enter”, soft key, a keyboard with several keys will appear. Press “Shift” to
select special characters. Press “Caps” to select capital letters. Press soft key “OK” after entering a new
batch name.
5.5.1.1 Lot Number
Define the starting Lot number of the batch.
5.5.1.1.1 Auto Increment
If this option is enabled then the lot number will be automatically incremented by one for the next
batch.
5.5.2 Desc
The description about the batch for logging.
