Page 31 of 479
1.9.6.4 Output1/Output2
1. Relay Rating:
2A/240 VAC, life cycles 200,000 for Resistive load
2. Pulsed Voltage:
Source Voltage 5V, current limiting resistance 66Ω
3. Linear Output:
Resolution: 15 bits
Output Regulation: 0.01 % for full load change
Output Settling Time: 0.1 sec. (stable to 99.9 %)
Isolation Breakdown Voltage: 1000 VAC
Temperature Effect: ±0.0025 % of SPAN /°C
Linear Output Characteristics:
Type
Zero Tolerance
Span Tolerance
Load Capacity
4 to 20mA
3.8-4 mA
20-21 mA
500 Ω max
0 to 20mA
0 mA
20-21 mA
500 Ω max
0 to 5V
0 V
5 -5.25 V
10KΩ min
1 to 5V
0.95 to 1V
5 -5.25 V
10KΩ min
0 to 10V
0 V
10 - 10.5 V
10KΩ min
4. Triac (SSR) Output:
Rating: 1A / 240 VAC
Inrush Current: 20A for 1 cycle
Min. Load Current: 50 mA RMS
Max. Off-state Leakage: 3 mA RMS
Max. On-state Voltage: 1.5 V RMS
Insulation Resistance: 1000 MΩ minimum at 500 VDC
Dielectric Strength: 2500 VAC for 1 minute
SSR Output Characteristics:
Type
Tolerance
Maximum
Output
Current
Ripple
Voltage
Isolation
Barrier
20V
±0.5 V
25 mA
0.2 Vp-p
500 VAC
12V
±0.3 V
40 mA
0.1 Vp-p
500 VAC
5V
±0.15 V
80 mA
0.05 Vp-p
500 VAC
1.9.6.5 Alarm 1/ Alarm 2
Alarm 1 Relay: Form C, Max. Rating 2A/240VAC, life cycles 200,000 for resistive load
Alarm 2 Relay: Form C, Max. Rating 2A/240VAC, life cycles 200,000 for resistive load
Alarm Mode: Normal, Latching, Hold, Latching / Hold
Dwell Timer: 0 - 6553.5 minutes
Alarm Functions:
Dwell timer, Deviation High / Low Alarm, Deviation Band High / Low Alarm, PV1 High /
Low Alarm, PV2 High / Low Alarm, PV1 or PV2 High / Low Alarm, PV1-PV2 High / Low
Alarm, Loop Break Alarm, Sensor Break Alarm
1.9.6.6 Control Mode
Output 1: Reverse (heating) or direct (cooling) action
Output 2: PID cooling control, cooling P band 1~255% of PB
