5.10.10 Data Transfer
The data transfer option can be set as Dump and Clear or Transfer and Remain. Dump and
Clear will clear the data from internal memory after dumping. Transfer and remain will keep the data in
internal memory after dumping.
5.10.10.1 Show Message at the End
This will enabling or disabling the conformation message after dumping is finished.
5.10.11 Custom Page
The user can enable or disable the custom page download via Ethernet from Panel Studio
Software by choosing Enable or Disable in Allow Download via Ethernet.
5.10.11.1 Power on
The user can set a custom page to display after power on. This set page will show after the
recorder after power on.
5.10.12 Setup Start-up Image
The user can add a start-up image like a logo to shown during power on.
5.10.12.1 Procedure to Setup a Start-up Image
1. Copy the image to main path of SD Card or USB Disk
2. Insert the external storage to PR
3. Set the external storage to SD card or USB as per the connected storage
4. Select the image by using the setup start-up page option in Instrument menu.
