Brainchild PR10 User Manual

Page 123 of 479
*B19: Failure transfer mode for output 1 and output 2, select BPLS ( Bumpless transfer ) or 0.0 ~
100.0 % to continue output 1 and output 2 control function as the unit fails , power starts or manual
mode starts.
*B20: Display Symbol and Description for OUT2
Parameter Value
Display Symbol
Description
0
NONE
Output 2 no function
1
COOL
PID cooling control
3
DCPS
DC power supply module installed
5-20 Out2 Function
*B21: Display Symbol and Description for DISF
Parameter Value
Display Symbol
Description
0
PV
Display PV Value
1
SV
Display SV Value
5-21 Display Function
*B22: Display Symbol and Description for A1FN & A2FN
Parameter Value
Display Symbol
Description
0
NONE
No alarm function
1
TIMR
Dwell timer action
2
DE.HI
Deviation high alarm
3
DE.LO
Deviation low alarm
4
DB.HI
Deviation band out of band alarm
5
DB.LO
Deviation band in band alarm
6
PV1.H
IN1 process value high alarm
7
PV1.L
IN1 process value low alarm
8
PV2.H
IN2 process value high alarm
9
PV2.L
IN2 process value low alarm
10
P1.2.H
IN1 or IN2 process value high alarm
11
P1.2.L
IN1 or IN2 process value low alarm
12
D1.2.H
IN1 IN2 difference process value high alarm
13
D1.2.L
IN1 IN2 difference process value low alarm
14
LB
Loop break alarm
15
SEN.B
Sensor break or A-D fails
5-22 Alarm1 & Alarm2 Function
*B23: Display Symbol and Description for A1MD & A2MD
Parameter Value
Display Symbol
Description
0
NORM
Normal alarm action
1
LTCH
Latching alarm action
2
HOLD
Hold alarm action
3
LT.HO
Latching & Hold action
5-23 Alarm1 & Alarm2 Operation Mode
*B24: Display Symbol and Description for A1FT & A2 FT
Parameter Value
Display Symbol
Description
0
OFF
Alarm Output OFF as unit Fails
1
ON
Alarm Output ON as unit Fails
5-24 Alarm1 & Alarm2 Failure transfer mode
*B25: Display Symbol and Description for SFLF
Parameter Value
Display Symbol
Description
0
NONE
Auto tuning (Self Tune) Function disabled
1
YES
Auto tuning (Self Tune) Function Enabled
5-25 Self Tuning
*B26: Display Symbol and Description for SLEP
