Brainchild PR10 User Manual

Page 411 of 479
Modbus Address
Notation
Register Name
Access
411
C1_EIFN
Event input function
7
0 : None
1 : SP2
2 : PID2
3 : SP.P2
4 : RS.A1
5 : RS.A2
6 : R.A1.2
7 : D.O1
8 : D.O2
9 : D.O1.2
10 : LOCK
R
412
Reserve
Reserve
R
413
C1_SP1
Set point 1
R
414
C1_SP2
Set point 2
R
415
C1_Profile
Profile number
R
416
C1_Segment
Segment number
R
417
C1_Cycle
Cycle remaining for the current loop
R
418
C1_Run
Profile running
R
419
C1_Hold
Profile held
R
420
C1_Up
Running ramp up segment
R
421
C1_Down
Running ramp down segment
R
422
C1_Unit
Current input unit
R
423
C1_ProfileERROR
Profile error
0 : Normal
1 : Holdback timeout
R
424
C2_PV
Current process value
R
425
C2_SV
Current set point Value
R
426
C2_PVMD
PV mode selection
1
0 : PV1
1 : PV2
2 : PV1 - 2
3 : PV2 - 1
R
427
C2_IN1U
IN1 unit selection
2
0 : ℃
1 : ℉
2 : PU
R
428
C2_IN2U
IN2 unit selection
3
0 : ℃
1 : ℉
2 : PU
R
429
C2_MV1
Current output 1 value
R
430
C2_MV2
Current output 2 value
R
431
C2_ALM
Contains conditional code of parameters' resolution and current alarm status
4
R
432
C2_ERROR
Current error code
5
R
433
C2_SPMD
Set point mode selection
6
0 : SP1.2
1 : MIN.R
2 : HR.R
3 : PV1
4 : PV2
5 : PUMP
R
