Brainchild PR10 - Page 413

Page 413 of 479
Modbus Address
Notation
Register Name
Access
457
C3_EIFN
Event input function
7
0 : None
1 : SP2
2 : PID2
3 : SP.P2
4 : RS.A1
5 : RS.A2
6 : R.A1.2
7 : D.O1
8 : D.O2
9 : D.O1.2
10 : LOCK
R
458
Reserve
Reserve
R
459
C3_SP1
Set point 1
R
460
C3_SP2
Set point 2
R
461
C3_Profile
Profile number
R
462
C3_Segment
Segment number
R
463
C3_Cycle
Cycle remaining for the current loop
R
464
C3_Run
Profile running
R
465
C3_Hold
Profile held
R
466
C3_Up
Running ramp up segment
R
467
C3_Down
Running ramp down segment
R
468
C3_Unit
Current input unit
R
469
C3_ProfileERROR
Profile error
0 : Normal
1 : Holdback timeout
R
470
C4_PV
Current process value
R
471
C4_SV
Current set point Value
R
472
C4_PVMD
PV mode selection
1
0 : PV1
1 : PV2
2 : PV1 - 2
3 : PV2 - 1
R
473
C4_IN1U
IN1 unit selection
2
0 : ℃
1 : ℉
2 : PU
R
474
C4_IN2U
IN2 unit selection
3
0 : ℃
1 : ℉
2 : PU
R
475
C4_MV1
Current output 1 value
R
476
C4_MV2
Current output 2 value
R
477
C4_ALM
Contains conditional code of parameters' resolution and current alarm status
4
R
478
C4_ERROR
Current error code
5
R
479
C4_SPMD
Set point mode selection
6
0 : SP1.2
1 : MIN.R
2 : HR.R
3 : PV1
4 : PV2
5 : PUMP
R
