Modbus Address
Notation
Register Name
Access
572
C8_EIFN
Event input function7
0 : None
1 : SP2
2 : PID2
3 : SP.P2
4 : RS.A1
5 : RS.A2
6 : R.A1.2
7 : D.O1
8 : D.O2
9 : D.O1.2
10 : LOCK
R
573
Reserve
Reserve
R
574
C8_SP1
Set point 1
R
575
C8_SP2
Set point 2
R
576
C8_Profile
Profile number
R
577
C8_Segment
Segment number
R
578
C8_Cycle
Cycle remaining for the current loop
R
579
C8_Run
Profile running
R
580
C8_Hold
Profile held
R
581
C8_Up
Running ramp up segment
R
582
C8_Down
Running ramp down segment
R
583
C8_Unit
Current input unit
R
584
C8_ProfileERROR
Profile error
0 : Normal
1 : Holdback timeout
R
Note 1: PVMD
Parameter Value
Display Symbol
Description
0
PV1
Use PV1 as process value
1
PV2
Use PV2 as process value
2
P1 - 2
Use PV1 - PV2 (difference) as process value
3
P2 - 1
Use PV2 - PV1 (difference) as process value
Note 2, 3: IN1/IN2 unit
Parameter Value
Display Symbol
Description
0
℃
Degree C unit
1
℉
Degree F unit
2
PU
Process unit
Note 4: ALM
MSB LSB
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
=BIN2K
If BIN2= 8~18, then
BIN2K=00
If BIN2=1, then BIN2K=01
If BIN2=19, 21, 22, 23 then
BIN2K=10
Otherwise, BIN2K=11
=ALMK
=00: No Alarm
activated
=01: Alarm 1
activated
=10: Alarm 2
