Assembling Note: If the upper ADF chute is replaced, attach a new antistatic brush and three
ejection support films to the new chute so that their front ends become aligned with the ribs
(shown in red below).
Underside of
the upper ADF chute
(3_034_1)
Ejection support films
Antistatic brush
Ribs
Ribs
(Front)
(Left)
