BRP-Rotax
INSTALLATION MANUAL
Fusebox The Fusebox needs to connected with the 28 V AC-DC Converter assy..
916 i TYPE C24
Figure 3.14
1 Fusebox 2
Connector to 28 V AC-DC Converter
assy.
Effectivity: 916 i A / C24
Edition 0/Rev. 1
24–00–00
Page 15
December 01 2023
