Once the output type has been selected, use the Left/Right arrows to move the
highlight into the % FS column of the output to be checked. Press until the % FS
value reads 0.000. To adjust the zero (Offset), use the Left/Right arrows to
highlight the Offset column and press to open the field. Make a small adjustment to
the Offset value and then press to close the field. Repeat this procedure as
necessary.
To adjust the output to Full Scale, use the Left/Right arrows to move the
highlight into the % FS column and press until the % FS column value reads 100.0.
Then use the Left/Right arrows to highlight the Gain column. Press to
open the field. Make a small adjustment and press again to close the field and check
the output. Repeat this procedure as necessary for other outputs.
When you are finished making all your changes press to save them. You will return
to the Programmable Analogs menu.
NOTE: Failure to save your adjustments will result in the numbers reverting back to the
defaults after power is turned off and back on.
The following table includes typical Programmable Analog Output values:
