CAI 700M - Modbus Map; 1 H Single-Read Coil

700M HFID 6-2-15
196
Modbus Map
01H Single-Read Coil
Modbus Commands Use TCP/IP Port 502. (Do not change TCP/IP port from 7700.)
Coil Numbers and Descriptions
Coil Number
Read Data
1
No Flame
2
Sample Pressure
3
Air Temperature
4
Fuel Temperature
5
Air Inject Pressure (if fitted)
6
Fuel Inject Pressure (if fitted)
7
Filter Temperature
8
Burner Temperature
9
Oven Temperature
10
Cutter Temperature
11
Pump Temperature
12
Sample EPC Voltage
13
Air EPC Voltage
14
Fuel EPC Voltage
15
Air Inject EPC Voltage (if fitted)
16
Fuel Inject EPC Voltage (if fitted)
17
Range OverFlow
18
ADC OverFlow
19
ADC UnderFlow
20
Range 1 Calibration Error
21
Range 2 Calibration Error
22
Range 3 Calibration Error
23
Range 4 Calibration Error
24
Low Concentration
