Maximum Calibration Error
→ → → → →
Maximum Calibration Error is used by the operator to define the maximum acceptable
tolerances for Absolute and Relative deviations. Each range has its own set of Absolute and
Relative tolerances. The deviations must be inside these tolerances to accept a calibration. To
access the Maximum Calibration Error screen, press from the Deviation Limits menu.
To navigate between fields, use the up or down arrow to move the highlight to the
field you intend to change. Press to open the field to change the allowable tolerance in %.
Press again to close the field. Press to save your changes.
Absolute Deviation is used to compare the factory-set calibration to the current calibration.
Relative Deviation compares the current calibration to the previous calibration.
