700M HFID 6-2-15
116
Programmable Digital Output List
Alarms_________________________________________________________________
• Flame: No Flame
• SampP: Sample Pressure
• AirP: Air Pressure
• FuelP: Fuel Pressure
• AinjP: Air Inject Pressure
• FinjP: Fuel Inject Pressure
• FiltT: Filter Temperature
• BurnT: Burner Temperature
• OvenT: Oven Temperature
• CuttT: Cutter Temperature
• PumpT: Pump Temperature
• SEPC: Sample EPC Voltage
• AEPC: Air EPC Voltage
• FEPC: Fuel EPC Voltage
• AIEPC: Air Inject EPC Voltage
• FIEPC: Fuel Inject EPC Voltage
• ROvr : Over Range
• AOvr: ADC Over Range
• AUnd: ADC Under Range
• R1NC: Range 1 not calibrated
• R2NC: Range 2 not calibrated
• R3NC: Range 3 not calibrated
• R4NC: Range 4 not calibrated
• Conc1: Concentration Alarm 1
• Conc2: Concentration Alarm 2
• GenAlarm: General Alarm
• Cal Alarm: Calibration Alarm
Statuses________________________________________________________________
• Zero: In Zero Mode
• Span: In Span Mode
• Sample: In Sample Mode
• InTHC: In THC Mode
• InCH4: In CH
4
Mode
• InOflow: In Wet Mode
• InPurge: In Purge
• Dual: In THC/CH
4
/NMHC
Mode
• InRem: In Remote
• AutoR: In Auto Range
• R1: In Range 1
• R2: In Range 2
• R3: In Range 3
• R4: In Range 4
• InCal: In Calibration Mode
