EDAL: Set Diagnostic Alarm Limits
Command
Response
Description
_EDAL_K0_ai.min_
a1.max_..._a16max
_EDAL_s
Set all alarm limits.
_EDAL_K0_x_
x.min_xmax
_EDAL_s
Set alarm limit of x.
Alarm Numbers and Descriptions
1
Sample Pressure
2
Air Pressure
3
Fuel Pressure
4
Air Inject Pressure
5
Fuel Inject Pressure
6
Filter Temperature
7
Burner Temperature
8
Oven Temperature
9
Cutter Temperature
10
Pump Temperature
11
EPC Coil Sample Voltage %
12
EPC Coil Air Voltage %
13
EPC Coil Fuel Voltage %
14
EPC Coil Air Inject Voltage %
15
EPC Coil Fuel Inject Voltage %
16
Concentration 1 / Concentration 2
