Printheads
1 1. Pull up the Printhead Fixer Cover to open it completely .
12. Remove the used Printhead .
Note
• Dispose of the used Printhead in accordance with local regulations.
13. Holding the new Printhead by the grips (a), remove it from the case.
Important
• When handling the Printhead , always hold it by the grips (a). Never touch the nozzles (b) or metal
contacts (c). This may damage the Printhead and af fect printing quality .
592 Maintenance
