Control Panel
Control Panel
Control Panel
a. Display Screen
Shows printer menus, as well as the printer status and messages.
b. Data Lamp (green)
• Flashing
During printing, the Data lamp ashes when the printer is receiving or processing print jobs.
Otherwise, this lamp ashes when the print job is paused or the printer is updating the rmware.
• Of f
There are no active print jobs when the Data lamp is of f.
c. Message Lamp (orange)
• On
A warning message is displayed.
• Flashing
An error message is displayed.
• Of f
The printer is of f or is operating normally .
d. Power button (green)
T urns the printer on and of f. ( → P .24)
The Power button is lit when the printer is on or in Sleep mode.
e. Stop button
Cancels print jobs in progress and ends the ink drying period.
f. Navigate button
Enables you to check instructions for loading and removing paper or replacing ink tanks or
printheads, as well as other operations. ( → P .29)
