Canon iPF650 - imagePROGRAF Color Inkjet Printer User Manual

Free Layout
Preferences Dialog Box
This dialog box appears when you select “Preferences” from the “imagePROGRAF Advanced Preview” menu.
Y ou can set the preferences for Free Layout.
“Units”
Set the unit for paper length, margins, and so on.
“Gridlines”
Y ou can input a grid line width value in numerical characters so that they serve as a guide to laying out objects.
Note
• Y ou can input between 10.0 and 200.0(mm) (between 0.39 and 7.87(inch)).
• Y ou can change the numbers by clicking either “▲” button or “▼” button.
“Divisions”
Y ou can change the number of divisions of grid lines so that they serve as a guide to laying out objects.
Note
• Y ou can input between 1 and 10.
• Y ou can change the numbers by clicking either “▲” button or “▼” button.
“Grid Color”
Select the grid line color .
“Print Object Frames”
Y ou can print the object border .
Note
• If you do not want to print the object border , deselect the “Print Object Frames” check box.
“Object Frame Style”
Y ou can select the object frame style for printing.
The following settings are available for the object frame style.
Setting
Details
“Solid Line” Y ou can print the solid line as the frame style.
“Dotted Line” Y ou can print the dotted line as the frame style.
“Dashed Line” Y ou can print the dashed line as the frame style.
Mac OS X Software 521

Canon iPF650 - imagePROGRAF Color Inkjet Printer Specifications

General

Printer Type	Large Format Printer
Print Technology	Inkjet
Maximum Print Resolution	2400 x 1200 dpi
Number of Ink Colors	5
Number of Nozzles	15, 360
Ink Cartridge Capacity	130 ml
Media Thickness	0.07 - 0.8 mm
Memory	256 MB
Operating Systems	Windows, Mac OS
Print Speed (Color)	Approx. 1.5 minutes (A1)
Print Speed (Black & White)	Approx. 1.5 minutes (A1)
Ink Colors	Cyan, Magenta, Yellow, Black, Matte Black
Ink Cartridges	PFI-102
Media Size	A4, A3, A2, A1
Media Width	24 inches
Media Sizes	A1, A2, A3, A4, B1, B2, B3, B4, 24", 36", 44"
Media Types	Plain Paper, Coated Paper, Fine Art Paper
Media Handling	Roll Feed, Manual Feed
Connectivity	USB, Ethernet
Interface	USB 2.0, Ethernet
Weight	46 kg
Weight (Approx.)	46 kg
