Canon iPF650 - imagePROGRAF Color Inkjet Printer User Manual

Free Layout
Page Options Dialog Box
This dialog box appears when you select “Page Options” from the “File” menu. This allows you to congure the roll
paper length, object layout order , and margins of Free Layout.
“Roll Paper Length”
Set the length of one page to print on roll paper .
The following settings are available for roll paper length.
Setting
Details
“Auto Settings” The one-page length to be printed on roll paper is automatically set so that
the laid-out objects are printed on one page.
“Manual Settings” Y ou can input the length of one page to print on roll paper in numerical
characters.
Note
• A vailable only if rolls are selected in Paper Source .
• Y ou can input between 203.2 and 18000.0(mm) (between 8.00 and 708.66(inch)).
• Y ou can change the numbers by clicking either “▲” button or “▼” button.
“Order”
Set the object layout order .
The following settings are available for order .
Setting
Details
“Upper Left to Right” The objects are laid out from upper left to right.
“Upper Left to Bottom” The objects are laid out from upper left to bottom.
“Upper Right to Left” The objects are laid out from upper right to left.
“Lower Left to T op” The objects are laid out from lower left to top.
Note
• When you have selected “Roll Paper Length” > “Auto Settings” and “Paper Orientation” > “V ertical” , you
can choose “Upper Left to Right” or “Upper Right to Left” .
• When you have selected “Roll Paper Length” > “Auto Settings” and “Paper Orientation” > “Horizontal” ,
you can choose “Upper Left to Bottom” or “Lower Left to T op” .
Windows Software 397

Canon iPF650 - imagePROGRAF Color Inkjet Printer Specifications

General

Printer Type	Large Format Printer
Print Technology	Inkjet
Maximum Print Resolution	2400 x 1200 dpi
Number of Ink Colors	5
Number of Nozzles	15, 360
Ink Cartridge Capacity	130 ml
Media Thickness	0.07 - 0.8 mm
Memory	256 MB
Operating Systems	Windows, Mac OS
Print Speed (Color)	Approx. 1.5 minutes (A1)
Print Speed (Black & White)	Approx. 1.5 minutes (A1)
Ink Colors	Cyan, Magenta, Yellow, Black, Matte Black
Ink Cartridges	PFI-102
Media Size	A4, A3, A2, A1
Media Width	24 inches
Media Sizes	A1, A2, A3, A4, B1, B2, B3, B4, 24", 36", 44"
Media Types	Plain Paper, Coated Paper, Fine Art Paper
Media Handling	Roll Feed, Manual Feed
Connectivity	USB, Ethernet
Interface	USB 2.0, Ethernet
Weight	46 kg
Weight (Approx.)	46 kg
