Messages regarding printheads
Messages regarding printheads
Cannot adjust printhead.
Cause Corrective Action
The Printhead nozzles are clogged. Execute Head Posi. Adj. again, as follows.
1. Press the OK button to clear the error .
2. Print a test pattern to check the nozzles.
( → P .630)
3. Clean the Printhead if the nozzles are clogged.
( → P .632)
4. Execute Head Posi. Adj. again.
( → P .604)
The Printhead cannot be aligned; highly transparent
lm is loaded.
Press the OK button to clear the error .
W e recommend using a type of paper that you often
use, other than lm, for Printhead adjustment.
( → P .604)
The Printhead is installed crooked. Straighten the Printhead as follows, and then execute
Head Posi. Adj. again.
1. Press the OK button to clear the error .
2. Use Head Inc. Adj. to adjust the angle of
inclination of the Printhead .
( → P .608)
3. Execute Head Posi. Adj. again.
( → P .604)
W rong printhead.
Cause Corrective Action
An incompatible Printhead has been installed. Open the T op Cover and replace the Printhead with
a new one.
( → P .633)
Printhead error
Cause Corrective Action
There is a problem with the Printhead . Open the T op Cover and replace the Printhead with
a new one.
( → P .633)
Error Message 707
