Canon iPF650 - imagePROGRAF Color Inkjet Printer User Manual

Free Layout
Prints using Folded Duplex
Allows you to produce duplex printing by combining two pages and folding them.
“Folded Duplex”
Any two pages can be arranged and printed in a layout that becomes duplex on folding.
This can be used such as for advertising posters that are suspended from the ceiling.
1. Select two objects from the layout area of Free Layout.
2. Select Folded Duplex from the “Edit” menu of Free Layout.
Open the Folded Duplex window and arrange the selected objects in the layout area.
3. Open the “Finished Size Settings” dialog box from the “Edit” menu.
4. Select “Fit Roll Paper Width” or “Specify Folded Size” in “Finished Size” .
Note
• “Rotate Page 90 degrees (Conserve Paper)” is also available when “Specify Folded Size” is selected.
5. Click “OK” to save the settings.
6. Open the “Binding Settings” dialog box from the “Edit” menu.
7. Select “Bottom” or “T op” in “Binding Edge” .
8. Specify the “Binding” width in “Binding” .
9. Congure the Fold Line Color and Fold Line T ype from Print Fold Lines .
Note
• When the Only Print Center and Edges checkbox is selected, fold lines are only printed at the
three locations of the center and both edges.
10. Click “OK” to save the settings.
1 1. Conrm the print setting and begin printing.
418 Windows Software

Canon iPF650 - imagePROGRAF Color Inkjet Printer Specifications

General

Printer Type	Large Format Printer
Print Technology	Inkjet
Maximum Print Resolution	2400 x 1200 dpi
Number of Ink Colors	5
Number of Nozzles	15, 360
Ink Cartridge Capacity	130 ml
Media Thickness	0.07 - 0.8 mm
Memory	256 MB
Operating Systems	Windows, Mac OS
Print Speed (Color)	Approx. 1.5 minutes (A1)
Print Speed (Black & White)	Approx. 1.5 minutes (A1)
Ink Colors	Cyan, Magenta, Yellow, Black, Matte Black
Ink Cartridges	PFI-102
Media Size	A4, A3, A2, A1
Media Width	24 inches
Media Sizes	A1, A2, A3, A4, B1, B2, B3, B4, 24", 36", 44"
Media Types	Plain Paper, Coated Paper, Fine Art Paper
Media Handling	Roll Feed, Manual Feed
Connectivity	USB, Ethernet
Interface	USB 2.0, Ethernet
Weight	46 kg
Weight (Approx.)	46 kg
