Printheads
Access the menu for Printhead replacement
Caution
• When replacing the Printhead immediately after printing, wait a few minutes before replacing it. The
metal parts of the Printhead become hot during printing, and there is a risk of burns from touching
these parts.
Note
• Prepare a new Ink T ank when ink levels are low .
• Y our hands may become dirty during Printhead replacement. Use the gloves provided with the new
Printhead for replacement.
1. If the roll is not ejected because of the cutting method selected, cut it manually and remove it.
( → P .331)
2. Clean inside the T op Cover . ( → P .647)
3. On the T ab Selection screen of the Control Panel , press ◄ or ► to select the Settings/Adj.
tab ( ).
Note
• If the T ab Selection screen is not displayed, press the Menu button.
4. Press the OK button.
The Set./Adj. Menu is displayed.
5. Press ▲ or ▼ to select Maintenance , and then press the OK button.
6. Press ▲ or ▼ to select Replace P .head , and then press the OK button.
Ink is now lled.
After about two minutes, a message is shown on the Display Screen instructing you to open
the T op Cover .
634 Maintenance

Canon iPF650 - imagePROGRAF Color Inkjet Printer Specifications

General

Printer Type	Large Format Printer
Print Technology	Inkjet
Maximum Print Resolution	2400 x 1200 dpi
Number of Ink Colors	5
Number of Nozzles	15, 360
Ink Cartridge Capacity	130 ml
Media Thickness	0.07 - 0.8 mm
Memory	256 MB
Operating Systems	Windows, Mac OS
Print Speed (Color)	Approx. 1.5 minutes (A1)
Print Speed (Black & White)	Approx. 1.5 minutes (A1)
Ink Colors	Cyan, Magenta, Yellow, Black, Matte Black
Ink Cartridges	PFI-102
Media Size	A4, A3, A2, A1
Media Width	24 inches
Media Sizes	A1, A2, A3, A4, B1, B2, B3, B4, 24", 36", 44"
Media Types	Plain Paper, Coated Paper, Fine Art Paper
Media Handling	Roll Feed, Manual Feed
Connectivity	USB, Ethernet
Interface	USB 2.0, Ethernet
Weight	46 kg
Weight (Approx.)	46 kg
