Canon iPF650 - imagePROGRAF Color Inkjet Printer User Manual

Adjusting the Printhead
6. Press ▲ or ▼ to select Manual , and then press the OK button.
A test pattern is printed for adjustment.
7. Press ▲ or ▼ to select D , and then press the OK button.
8. Press ▲ or ▼ to select D-1 , and then press the OK button.
9. Examine adjustment test pattern D-1 and determine the number with straight lines.
Note
• If two patterns seem equally good and you cannot decide which one is better , choose an intermediate
value.
For example, choose 1 1 if you cannot decide whether pattern 10 or 12 is better .
10. Press ▲ or ▼ to select the pattern number you have decided, and then press the OK button.
1 1. Repeat steps 8-10 to specify the adjustment value for D-2 to D-5 and D-7 to D-1 1 .
12. Press the Back button.
13. Press ▲ or ▼ to select Register Setting , and then press the OK button.
14. Press ▲ or ▼ to select Y es , and then press the OK button.
The adjustment value is now registered, and adjustment is complete.
Adjustments for Better Print Quality 607

Canon iPF650 - imagePROGRAF Color Inkjet Printer Specifications

General

Printer Type	Large Format Printer
Print Technology	Inkjet
Maximum Print Resolution	2400 x 1200 dpi
Number of Ink Colors	5
Number of Nozzles	15, 360
Ink Cartridge Capacity	130 ml
Media Thickness	0.07 - 0.8 mm
Memory	256 MB
Operating Systems	Windows, Mac OS
Print Speed (Color)	Approx. 1.5 minutes (A1)
Print Speed (Black & White)	Approx. 1.5 minutes (A1)
Ink Colors	Cyan, Magenta, Yellow, Black, Matte Black
Ink Cartridges	PFI-102
Media Size	A4, A3, A2, A1
Media Width	24 inches
Media Sizes	A1, A2, A3, A4, B1, B2, B3, B4, 24", 36", 44"
Media Types	Plain Paper, Coated Paper, Fine Art Paper
Media Handling	Roll Feed, Manual Feed
Connectivity	USB, Ethernet
Interface	USB 2.0, Ethernet
Weight	46 kg
Weight (Approx.)	46 kg
