Canon MF3110 - ImageCLASS Laser Multifunction - Drive Releasing Arm

Chapter 4ޓRunning H/F 5
4-14
4.5.10 Drive Releasing Arm
0002-7940
Area of application: [1]
Grease: MOLYKOTE EM50L
Amount: 10 +/5 mg
Location of application:
 4 locations on sliding surface against gear support shaft of drive releasing arm
F-4-13
[1]
