2.1 Document Feed and Exposure System
2.1.1 Overview/Configuration
2.1.1.1 Overview 0007-8185
F-2-1
T-2-1
The CCD unit driven by the flatbed motor reads out image data of a document on the platen glass.
[1] Flatbed motor
[2] CCD unit
[1]
[2]
