Canon MF3110 - ImageCLASS Laser Multifunction - Cassette Pickup Roller 4; Pressure Roller 4

Chapter 4
4-19
4.5.17 Pressure roller
0002-7953
Area of application: [1]
Grease: MOLYKOTE 41
Amount: 10 +/10 mg
Location of application:
 edge of pressure roller shaft (sliding surface against contact spring F)
F-4-20
4.5.18 Cassette Pickup Roller
0003-6451
Area of application: [1]
Grease: MOLYKOTE EM50L
Amount: approx. 10 mg
Location of application:
 cassette pickup roller shaft, main unit frame (around the bushing), and the area where contacts the cassette pickup
bushing
F-4-21
[1]
[1]
