Chapter 3ޓ
3-16
3.1.11.2 Removing the right
cover
0007-7533
1) Open the front cover [1], and remove the 2 screws
[2] on the front side.
F-3-63
2) Remove the 2 screws [1] on the back side, and
remove the right cover [2].
F-3-64
3.1.11.3 Removing the left
cover
0007-7534
1) Open the front cover [1], and remove the 2 screws
[2] on the front side.
F-3-65
2) Remove the 2 screws [1] on the back side, and
remove the left cover [2].
F-3-66
[1]
[2]
[1]
[2]
[1]
[2]
[1]
[2]
