Canon MF3110 - ImageCLASS Laser Multifunction - CCD Shaft 4; Wheel Shaft 4

4.5.19 CCD Shaft
0003-2409
Area of application: [1]
Grease: MOLYKOTE EM50L
Amount: suitable amount
Location of application:
 part of CCD shaft where contacts the CCD unit (all the faces in the shaft direction)
F-4-22
4.5.20 Wheel Shaft
0007-8738
Area of application: [1]
Grease: MOLYKOTE EM50L
Amount: suitable amount
Location of application:
 part of wheel shaft where contacts the wheel unit
F-4-23
[1]
[1]
