5.6.4.1.2 Test Mode Flowchart
0007-6680
To operate the test mode, after pressing the Menu key, press the # key and select "SERVICE MODE". After this,
select "TEST MODE" with the cursor keys, and press the OK key.
Turn OFF and back ON the power to end the Test Mode.
F-5-9
[1] DRAM TEST
[2] SCAN TEST
[3] PRINT TEST
[4] MODEM TEST
[5] AGING TEST
[6] FUNCTION TEST
[1] DRAM TEST
[2] DRAM TEST
[1] WHT
[2] BLK
[3] STRPS
[4] CHKRS
[5] CHKRS2
[6] ENDUR
[7] BK/WHT
[8] BIAS
[9] CHKRS3
[1] G3 4800bps TEST
[3] SENSOR
[4] ADF FEED TEST
[5] BOOK FEED TEST
[6] SPEAKER
[7] OPERATION PANEL
[8] LAMP TEST
[9] LINE TEST
TEST MODE
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
‘
*
’ indicates that these items
are not used in the field.
To Next Page
