CASE CONSTRUCTION CX145D SR - Overhead Controls; Roof Curtain; Roof Hatch; Sun Shield (Optional)

3-CONTROLSANDINSTRUMENTS
Overheadcontrols
Roofcurtain
Toopentheroofcurtain,slideittowardtherearusingthe
handles.T oclosethecurtainslideittowardthefront.
VHIVJ6-001A1
Roofhatch
Toopentheroofhatch,pushthetwolockinglevers(1)to
theinside,andfollowtheopeningmovementbyholding
thehandle(2).
NOTICE:Theroofhatchisttedwithtwogasstruts,and
theopeningmovementshallthusbefollowedthroughby
handinordernottodamagethemachine.
Toclosetheroofhatch,pullitdownuntilthetwolocking
levers(1)areengaged.
SMIL17CEX0898AA1
Sunshield(optional)
Thesunshieldisxedtothewindshieldandcaneasilybe
positionedasrequired.
R566HK-001A1
3-57
