CASE CONSTRUCTION CX145D SR - Parking the Unit; Parking the Machine

4-OPERATINGINSTRUCTIONS
Parkingtheunit
Parkingthemachine
WARNING
Fallhazard!
Jumpingonoroffthemachinecouldcauseaninjury.Alwaysfacethemachine,usethehandrails
andsteps,andgetonoroffslowly.Maintainathree-pointcontacttoavoidfalling:bothhandsonthe
handrailsandonefootonthestep,oronehandonthehandrailandbothfeetonthesteps.
Failuretocomplycouldresultindeathorseriousinjury.
W0141A
1.Parkthemachineonatandlevelareaawayfrom
softground,dugholesandgroundcavitywithoutsolid
support.
2.Orienttheupperstructureframeparalleltotheunder-
carriage,retracttheattachmentandtouchthebucket
togroundtormlysecurethemachine.
NOTE:FormachineinBLADEversion,makesureto
lowerthebladetotheground.
3.Setthegatelocklevertolockposition.
SMIL17CEX0198AA1
4.Turntheenginethrottle(1)tolowidleposition.
5.Waitforthegreencoolingdownicontoappear.
Theenginehascooleddownandcanbe
stopped.
NOTICE:Iftheengineisstoppedbeforetheiconap-
pears,thelubricatedsectionontheturbochargergets
driedfromthehighheat,leadingtoaturbochargerfail-
ure.
SMIL15CEXY892AB2
6.Turnthestarterkey(2)toOFFposition.
NOTE:Ifthesecurityfunctionissetup,theoptionfor
activatingthesecurityfunctionisdisplayed.
SMIL15CEXY892AB3
