CASE CONSTRUCTION CX145D SR - Dimensions

8-SPECIFICATIONS
Dimensions
CX145DSRLC
SMIL17CEX3810FA1
Arm
2.11m(83.07in)2.50m(98.43in)3.01m(118.50in)
(A)2.75m(108.27in)2.84m(111.81in)2.68m(105.51in)
(B)7.34m(288.98in)7.35m(289.37in)7.34m(288.98in)
(C)1.88m(74.02in)
(D)(withoutgrousers)0.88m(34.65in)
(E)3.04m(119.69in)
(F)3.76m(148.03in)[3.85m(151.57in)withrubberpads]
(G)2.49m(98.03in)
(H)2.82m(111.02in)[2.87m(112.99in)withrubberpads]
(I)(withfoldedhandrail)2.78m(109.45in)[2.83m(111.42in)withrubberpads]
(J)(withoutgrousers)0.42m(16.54in)[0.48m(18.90in)withrubberpads]
(K)(standardtrack)0.60m(23.62in)
(L)1.99m(78.35in)
(M)500mm(19.7in)trackorpad2.49m(98.03in)
(M)600mm(23.6in)track2.59m(101.97in)
(M)700mm(27.6in)track2.69m(105.91in)
Boomlength:4.63m(182.28in)
NOTICE:Forthe3.01m(118.50in)arm,thedimension(A)andthedimension(B)ofthereferencepositionshown
ingurearemeasuredwiththearmcylinderpinintransportposition.
8-6
