CASE CONSTRUCTION CX145D SR - Side Doors

3-CONTROLSANDINSTRUMENTS
Sidedoors
WARNING
Movingparts!
Makesureallentryandmechanicalaccessdoorsareproperlyclosedbeforeoperatingthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0238A
Openthesidedoorsuntiltheyarexedbythestays.Closethesidedoorsunlockingthestays.Makesuretoclose
thedoorsrmly.Usethestarterkeytolockthedoors.
Frontright-handdoor
Thefrontright-handdoorallowstoaccessthecompart-
mentincludingthecontrolvalveandthefueltankller
pump(ifequipped).
NOTE:Neverleavetoolsinsidethecompartment.
SMIL17CEX3246AA1
Rearright-handdoor
Therearright-handdoorallowstoaccessthecompart-
mentincludingtheengineoillter,thefuellters,the
fuelfeedpump,thehydraulicpilotlter,andthehydraulic
pump.
NOTE:Neverleavetoolsinsidethecompartment.
SMIL17CEX3245AA2
Left-handdoor
Theleft-handdoorallowstoaccessthecompartmentin-
cludingtheradiators,theengineaircleaner,thebattery,
thebatterydisconnectswitch,thereservetankforengine
coolant,thewindshieldwasherreservoir,andtheaircon-
ditioningdryer.
NOTE:Neverleavetoolsinsidethecompartment.
SMIL17CEX3244AA3
