CASE CONSTRUCTION CX145D SR - Track Tension

6-MAINTENANCE
Tracktension
WARNING
Tip-overhazard!
Onlyraisethetrackaslittleasnecessary.
Failuretocomplycouldresultindeathorseriousinjury.
W0276A
Checkthetracktensionperiodically
NOTICE:ifthetracksaretootight,theywearquickly.Iftracksarenottightenough,theywearquicklyandthelinks
cancatchonthesprocketwheelorslideofftheidlerwheelorthesprocketwheel.Cleanthetracksafterwork.
Tocheckthetrackstension,proceedasfollows:
1.Swingtheupperstructureperpendiculartotheun-
dercarriage.Lowertheattachmenttotheground,
thenlowertheboomuntilthetrackisraisedoffthe
ground.Placeablockundertheundercarriageand
raisetheattachmentofftheground.
SMIL17CEX0132AA1
2.Turntheenginespeedthrottletothemaximum
speedposition.
SMIL17CEX0107AA2
3.Pressthetravelmodeselectorbutton(1)tosetthe
"Rabbit"mode.
SMIL14CEX2853AB3
6-71
