CASE CONSTRUCTION CX145D SR - Windshield

3-CONTROLSANDINSTRUMENTS
Windshield
CAUTION
Pinchhazard!
Makesureyoucorrectlyfollowtheinstructionsinthismanualwhenhandlingthewindshield.Ifyou
donothandlethewindshieldcorrectly,itcouldslipandinjureyourngersorhands.
Failuretocomplycouldresultinminorormoderateinjury.
C0045A
Opening
1.Foldthesunshield(1)backagainstthewindshieldand
operatethelever(2).
2.Holdthelowerandupperhandles(3)andcarefully
raisethewindshield.
SMIL17CEX0900AA1
3.Pullthewindshieldtotherearuntilitengagesperfectly
behindthecab.
SMIL17CEX0899AA2
Closing
1.Operatethelever(2)toreleasethewindshield.
2.Holdbothhandles(3)andcarefullylowerthewind-
shield.Makesurethewindowiscompletelydown.
3.Makesurethetopofthewindshieldiscorrectly
latched.
SMIL17CEX0899AA3
3-11
