3-CONTROLSANDINSTRUMENTS
3-CONTROLSANDINSTRUMENTS###_3_###
Accesstooperator'splatform
Doorandsteps
CAUTION
Pinchhazard!
Becarefulnottogetyourhand,clothes,etc.caughtinthedoorwhenclosingit.
Failuretocomplycouldresultinminorormoderateinjury.
C0046A
Cabdoor
Toopenthedoor,usethehandle(1)fromtheoutsideand
usethehandle(2)fromtheinside.
NOTICE:Beforeopeningthedoorfromtheinside,make
suretoplacethegatelockleverinlockposition.Theleft-
handcontrollevermightbetouchedinadvertentlywhen
openingthedoor,andthemachinemaythusmovesud-
denlyandinadvertentlycausingsevereincidents.
SMIL17CEX0080AA1
SMIL17CEX0081AA2
Thedoorcanbelatchedincompletelyopenposition.
NOTICE:Neverworkleavingthedoorajar.Beforeper-
forminganyworkwiththedooropen,makesuretolockit
inthecompletelyopenposition.
Tounlatchthedoor,stopmachineoperation,setthegate
locklevertolockposition,andtiltthelever(3)downward.
SMIL17CEX0082AA3
3-1
