CASE CONSTRUCTION CX145D SR - Instrument Cluster

3-CONTROLSANDINSTRUMENTS
Instrumentcluster
(1)Ambientsensor
NOTE:Donotplaceanyobjectontheambientsensor:
theclimatecontrolsystemmaynotcorrectlycontrolthe
temperatureinsidethecab.
(2)Display
(3)Controlbuttons
(4)Airvents
NOTE:Theairventsshallbemanuallyset.Makesureto
settheopeningandthedirectionoftheairventsinorder
tograntthedesiredconditionintothecabenvironment.
NOTICE:Ifwatergetsinsidetheinstrumentcluster,itcan
beseriouslydamaged.Makesuretokeeptheinstrument
clusterprotectedfromwaterandfromanykindofuid.
Useonlyasoft,dryclothtocleantheinstrumentcluster.
(5)Cigarettelighterand24Vpowersupplysocket:the
deviceisactivewiththestarterkeyinONposition,orwhile
theengineisrunning.Tooperatethecigarettelighter,
pushitdowntoengageitsheatingposition.
NOTICE:keeppushingthecigarettelightercancausese-
riousdamagestothedeviceandtothemachineelectrical
system.
NOTICE:theelectricalsystemmaybedamagedifthe
cigarettelighterdoesnotreturntoitsoriginalpositionaf-
ter30s.PullitoutmanuallyandconsulttheCASECON-
STRUCTIONdealer.
NOTICE:connectonly24Vdevicestothesocket.Con-
nectingdevicesfunctioningatdifferentvoltagecancause
damagestothedeviceitselfandtotheelectricalsystem.
SMIL17CEX0139BA1
3-26
