CASE CONSTRUCTION CX145D SR - Radiator and Coolers

6-MAINTENANCE
Radiatorandcoolers
WARNING
Flyingdebris!
Compressedaircanpropeldirt,rust,etc.intotheair.Weareyeandfaceprotectionwhenusingcom-
pressedair.
Failuretocomplycouldresultindeathorseriousinjury.
W0307A
Cleantheradiatorevery500h
NOTICE:overheatmayoccuriftheprotectionnet,theradiatorn,ortheoilcoolernisclogged.
1.Stoptheengine,andremovethestarterkey.
2.Fullyopentherearleft-handdooruntilthedooris
xedbythestay.
NOTICE:alwayscheckthatthedoorisxedrmly.
SMIL17CEX3244AA1
3.Unlockthequick-connectclip(1),holdthehandles
(2)andpullouttheupperanti-dustnet(3).
4.Unlockthequick-connectclips(4),holdthehandle
(5)andpulloutthelowerprotectionnet(6).
5.Usecompressedairtoblowawaymudordirt
cloggedinthenetsandtheradiatorn.Steamor
compressedwatermaybeusedinsteadofcom-
pressedair.
NOTICE:Applyhigh-pressurevehicle-washsteamfroma
sufcientdistanceaway.Ifthesteamoutletistooclose,
theradiatornmaydeform.
NOTICE:Inpresenceofgreasyoroilydust,useper-
chlorethylene.Useoftrichloroethyleneisstrictlyforbidden.
SMIL17CEX3812AA2
6.Insertthelowerprotectionnet(6)intotheguide
rails,andleadittoitsrestingpositionbyholdingthe
handle(5).Lockthequickconnectclips(4).
7.Installtheanti-dustnet(3)andleaditintoitsresting
positionbyholdingthehandles(2).Lockthequick
connectclip(1).
8.Closeandlocktherearleft-handdoor.
SMIL17CEX3812AA3
6-44
