CASE CONSTRUCTION CX145D SR - Forward Controls

3-CONTROLSANDINSTRUMENTS
Forwardcontrols
Forwardcontrols
WARNING
Avoidinjury!
Inspecttheworkareaorjobsitetomakesurethatmachineoperationcanbedonesafely.Conrmthat
theleveroperationisthesameasindicatedonthecontrolpatternlabels.Ifnot,immediatelychange
themachinecontrolpatternorthelabeldisplayedtomatchthemachinecontrolpattern.
Failuretocomplycouldresultindeathorseriousinjury.
W1339A
Selectionofcontrolpatternbyselectorvalve
Switchingthevalveallowschangingoperationpatternofcontrollevers.
NOTICE:Makesuretostoptheenginebeforechangingtheoperationpatternofcontrollevers.
Selectionmethod:
1.Groundthebucketandthenstoptheengine.
2.Openthestoragecompartmentlocatedunderthecab.
3.Readandunderstandthewarninglabel(L)locatedontheinsideofthecompartmentcover.
SMIL17CEX0587EA1
4.Pulltheknob(1)andmovethelever(2)tosetthelevertothedesiredoperationpatternCorD.
SMIL17CEX0588EA2
5.Closethestoragecompartment.
3-7
