CASE CONSTRUCTION CX145D SR - Hydraulic Oil Level

6-MAINTENANCE
Hydraulicoillevel
WARNING
Burnhazard!
Beforeperforminganyserviceonthehydraulicsystem,youmustallowittocool.Hydraulicuid
temperatureshouldnotexceed40°C(104°F).
Failuretocomplycouldresultindeathorseriousinjury.
W0241A
Checkthehydraulicoillevelevery10horeveryday
Fluid:CASEAKCELAHYDRAULICLL46
1.Parkthemachineonaatandlevelplace,andarrange
theattachmentasshowninthegure.Stoptheengine,
andremovethestarterkey.
SMIL17CEX3276AA1
2.Accesstheladderontheright-frontofthemachine.
Theoillevelgaugeislocatedbehindtheboomfoot.
Theoilshouldbeinthemiddleoftheindicator.
SMIL17CEX3275AA2
3.Ifthehydraulicoillevelisnotinrangeproceedasfol-
lows:
•
Releaseallpressureinthehydraulictank.Referto
page6-10.
•
Removethepaneloverthehydraulictank.Cleanthe
topsurfaceofthehydraulictank.
•
Removethecoverofthesuctionlter,andsupply
hydraulicuidtothetank.
•
Ifnecessary,replacethesealofthecoverplate,and
attachthecoverofthesuctionlter.
•
Installthepaneloverthehydraulictank.
NOTICE:makesurethatnocontaminant(water,sandetc.)
entersthereservoirduringlling.
SMIL17CEX3531AA3
6-19
