5-TRANSPORTOPERATIONS
Loadingthemachineontoatransporttrailer
WARNING
Improperoperationorserviceofthismachinecanresultinanaccident.
Assignasupervisortodirectworksiteoperations.Agreeonallsafetymeasures,procedures,and
suitablehandsignals.
Failuretocomplycouldresultindeathorseriousinjury.
W0287A
WARNING
Transporthazard!
Themachinecansliporfallfromaramportrailer.Makesuretherampandtrailerarenotslippery.
Removealloil,grease,ice,etc.Movethemachineonoroffthetrailerwithmachinecenteredonthe
trailerorramp.
Failuretocomplycouldresultindeathorseriousinjury.
W0152A
Makesuretocheckthetotalweight,length,widthandheightofthemachinetobetransported.RefertoChapter8.
Makesuretouseatrailerwitharatedcapacityanddimensionssufcienttotransportthemachine.Ifarearloading
typetrailerisusedforroadtransport,makesurethatrampsareavailabletoclimbontothetrailerbed.Useramps
whichhavesufcientwidth,length,thicknessandstrength.Therampslopeshouldbe15°orless.
Investigatebeforehandtheconditionsoftheroadtobetraveled,weightandsizelimits,andspeciallocaltrafcregu-
lations.Obtainanypermitsrequiredfrompropergovernmentagenciesformachinetransportation.
Trailersetup
Positionthetraileronrmandlevelground.
Putblockstothetiresofthetrailertopreventtrailerfrom
moving.
Ifarearloadingtypetrailerisusedforroadtransport,
preparetheloadingramps.Iftherampsareincludedin
thetrailerframe,lowerthemtotheground.Iftheramps
areexternaltothetrailer,matchthemtotherearedge
ofthetraileravoidinganybumpbetweentrailerbedand
externalramps.
SMIL13CEX2717AB1
Machinesetup
Accuratelycleanthemachineundercarriageandtracksto
preventmudordebrisfromskiddingduringtransport.
Makesuretodeactivatetheautoidlefunctionandtheauto
shut-downfunction.Presstheidlemodebutton(1)until
anyidleicononthedisplayturnsoff.
Pressthetravelmodeselectorbutton(2)toselectthelow
travelspeed.The“Turtle”iconappearsonthedisplay.
SMIL14CEX2560AB2
5-3
