CASE CONSTRUCTION CX145D SR - Quick Coupler Buckets

9-ACCESSORIES
Quickcouplerbuckets
CASECONSTRUCTIONquickcoupler
CASECONSTRUCTIONcanprovideahydraulicquickcouplerandadedicatedrangeofCouplerbuckets.
TheCASECONSTRUCTIONCouplerbucketsaredesignedtooptimizethettingtotheCASECONSTRUCTION
quickcoupler,andthustooptimizetheoperatingperformanceofthemachine.
SMIL15CEX3064EA1
Maindimensions
(E)255mm(10in)
(G)385mm(15in)
(H)510.5mm(20.1in)
Weight
180kg(397lb)
NOTICE:usageofbucketsotherthanCASECONSTRUCTIONCouplerbucketsisstrictlylimitedtotheconditionthat
thebuckethangersmatchwiththedimensionsindicatedinthetablebelow.ContactyourCASECONSTRUCTION
dealerforcheckingthebucketsintendedforusage.
Bucketttingdimensions
Bucketpindiameter
60mm(2.4in)65mm(2.6in)
Minimumpinspread(A)345mm(13.6in)355mm(14.0in)
Maximumpinspread(B)415mm(16.3in)420mm(16.5in)
Seatingwidth(F)221mm(8.7in)
Quickcoupleridenticationplate
TheidenticationplateoftheCASECONSTRUCTIONquickcouplerislocatedontheinsideofthetophangers.
Serialnumber:
Weight:
Workingpressure:
Type/Model:
Partnumber:
Yearofmanufacture:
SWL(SafeWorkingLoad):
9-27
