CASE CONSTRUCTION CX145D SR - Gate Lock Lever

3-CONTROLSANDINSTRUMENTS
Gatelocklever
WARNING
Unexpectedmachinemovement!
Whenthemachineisnotinoperation,thegatelocklevermustbeintheLOCKposition.
Failuretocomplycouldresultindeathorseriousinjury.
W1487A
Thegatelockleverallowstocancelthefunctioningofthe
controlleversandpedals.
SMIL17CEX0199AA1
Thegatelockleverhastwopositions:
Unlockposition:whenthegatelockleverisinunlockpo-
sition,theattachment,thetravelfunctionsandtheswing
functionscanbeoperated.
NH00032
Lockposition:whenthegatelockleverisinlockposition,
allthefunctionsaredisabledandthelefthandconsoleis
fullyraised.Theoperatorcanthuseasilygetoffthecab.
NOTE:Setthegatelocklevertolockpositionwhenend-
ingmachineoperationandleavingthemachine.
NOTE:theenginemustbestartedwiththegatelocklever
inlockposition.Ifthegatelockleverisinunlockposition,
theenginedoesnotstart.
NH00023
3-15
