9-ACCESSORIES
Fieldviewmonitor
TheCASECONSTRUCTIONFieldViewMonitor(FVM)isasystemthatensurepropervisibilityduringoperationby
displayingacomprehensivevisualizationoftheareaaroundthemachine.
Thecomprehensivevisualizationisbasedonthecombi-
nationoftheviewsofthreeexternalcameras:arearcam-
era(1)installedonthecounterweight,aright-sidecam-
era(2)installedonthefueltank,aleft-sidecamera(3)
installedabovetheleft-handdoor.
NOTICE:Neveroperatethemachinewhileonlylooking
attheimagesonthedisplay.Makesuretocheckthe
areaaroundthemachinebythedirectvieworthrough
themirrors.
NOTICE:Ifanymud,raindrops,snow,etc.areadhered
tothecameralens,theimagesonthedisplayaredeteri-
orated.Wipeawaydirtwithawetandsoftcloth,andthen
wipeitwithadryandsoftcloth.Makesurenottoscratch
thecameras.
SMIL17CEX3248AA1
FVMmodeofthedisplay
TheFVMmodeofthedisplayisalternativetothenormaloperatingmode.Pressthecameraviewselectorbuttonon
theinstrumentclustertoselecttheFVMmode.Theoperatingmodeofthedisplaytoggleseverytimethebuttonis
pressed.
SMIL17CEX1334EA2
NOTICE:Duringmachineoperation,makesuretoselecteitheroneoperatingmodeofthedisplayinordertoensure
propervisibilityaroundthemachine.Ifthedisplayisswitchedtotheuserinformationmodeduringmachineoperation,
thewarningmessageSELECTCAMERASCREENDURINGOPERATIONwillappearonthetopofthedisplay.
