3-CONTROLSANDINSTRUMENTS

Mirrors

SMIL17CEX3552EA1

(A)Top-leftmirror—(B)Bottom-leftmirror—(C)Right-sidemirror

Installationandpositioningofthemirrors

WARNING

Avoidinjuryand/ormachinedamage!

Keepthemirrorscleanandproperlyadjusted.

Failuretocomplycouldresultindeathorseriousinjury.

W1078A

Theexternalmirrors,alongwiththeexternalcameras,en-

surepropervisibilityaroundthemachineduringoperation.

Thehatchedareasinthepicturesindicatethezonesthat

canbeviewedbyeachmirror.

SMIL17CEX3249AA2

3-60
